2.4Hz global universal signal, stable transmission, anti-interference
Supports dual transmitters
Manual pairing and automatic pairing
One key to forcing all transmitters off
Transmission distance of tour guide systems up to 150 m
Support auxiliary audio transmission
16-port USB charging base
This charging dock can charge up to 16 receivers at the same time, and it has eight safety protections to maximize the protection of the battery of the tour guide system, and LED indicators and control switches are more convenient to use.
Dual transmitter support
If your tour group needs two guides in order to provide better service to your visitors, you can choose this system where all receivers can hear both transmitters.
Lightweight and portable
With the transmitter weighing 70g and the receiver weighing only 18g, your tourists will surely feel comfortable while wearing it. And the rear-mounted receiver doesn't have to be worn in the ear, so it's cleaner and more hygienic.
AUX interface
The transmitter has a dedicated AUX port to connect external audio devices for audio input, such as smartphones, laptops, church sound systems, etc.
Working hours
The transmitter has a built-in 1300mAh rechargeable lithium battery, 3H fully charged, 25H continuous use. The receiver has a built-in 380mAh, 2H fully charged, 23H continuous use.
One key to mute the sound
Sometimes the tour guide doesn't want tourists to hear some of his words, he can press the mute button, and the tourists can't hear his voice.
Please fill in your procurement needs and contact information
| TT106 Wireless Transmitter | TT106 Wireless Receiver | ||
| Frequency Range | 2400~2483MHz | Frequency Range | 2400~2483MHz |
| ID Number | 9999 | ID Number | 9999 |
| Supply Voltage | DC3.7V | Supply Voltage | DC3.7V |
| Transmitting power | ≦50mW | TIS | -90dBm |
| Frequency stability | ±0.001﹪ | Frequency stability | ±0.001﹪ |
| SNR | 80dB | SNR | 80dB |
| Size | 97*63*18mm | Size | 65*58*11mm |
| Weight | 70g | Weight | 18g |
| Charge time | 3H | Charge time | 2H |
| Working time | 25H | Working time | 23H |
| Battery specification | 3.7V/1300mA | Battery Specification | 3.7V/380mA |
| Charge Jack | MINI USB | Charge Jack | MINI USB |
| Modulation frequency deviation | ±320KHz | Modulation frequency deviation | ±320KHz |
| Working current | 62mA | Working current | 15mA |
| Communication range | 150m (open air) | Standby current | 1mA |
| Charging voltage | DC5V | Charging current | 320mA |
| Communication range | 150m (open air) | ||
| Charging voltage | DC5V | ||
Specifications of TT002 16-port USB Charging Base
USB output: DC 5V; 7A
Adapter input : AC100-240V 50/60Hz
Size: 190 x 95 x 50mm
Weight: 430g
