This FM listening system is a smart choice for churches, conferences, schools, and other large-range venues.
The transmitter can be preset with 3 stations and the receiver can be preset with 5 stations
Select mono and stereo as needed
PR13 FM receiver with locking key and headphones
4 types of input U disk / Bluetooth / Aux / Mic
Adding Input Modes
The FM radio transmitter adds Bluetooth (range over 10m), USB stick and 2 Mic Jacks input options, making the FM transmitter even more useful.
Volume adjustment
TR510 stationary FM transmitter can adjust the volume of input audio and microphone. Alternatively, listeners can adjust the volume of the PR13 FM receiver they are wearing.
Three-stage output power
The long-range FM transmitter supports 3 levels of output power (1W/3W/5W), so you can choose the right output power according to the size of the range you want to cover, with a transmission range of up to 1000 meters at maximum output power.
Quick pairing
Set the frequency of the transmitter first, then set the TR101 receiver to the same channel for successful pairing.
Stable signal
FM transmitter adopts the latest QN8007 chip, it has more stable signal, less noise, and anti-frequency interference, anti-eavesdropping, and improve the security of group conversation.
Other advantages:
Support dual microphone
Transmitter can be set to play audio sequentially or cyclically
FM radio stations are compatible with all portable FM radios and car radios
Please fill in your procurement needs and contact information
The Specification of TR510 Transmitter
Working voltage: DC 12V±10%, 1A
Frequency response:≤±1.5dB(100Hz～10KHz)
Audio input level: 0dBm/600Ω（unbalanced）
Frequency error：≤1KHz
RDS encoding method: DPSK
RDS subcarrier frequency: 57KHz±6Hz
Maximum frequency deviation:±75KHz
RDS frequency deviation:± 2.4KHz
Pre-emphasis: 50μS/70μS
Audio output amplitude: 2000mVpp
Audio total harmonic distortion:≤1%
Playable Audio format: MP3、WAV、APE、WMA
Signal-to-noise ratio:≥55dB
Working temperature:-25℃～+45℃
Residual wave radiation:＜60dB
Antenna Type: SMA
The Specification of PR13 Radio Receiver
Sensitivity:<3.5uV
Signal to noise ratio: 45db
Stereo separation: 32dB
Power supply: 2 x AAA batteries (not included)
Earphone jack: 3.5mm
Tuning increase: 0.1MHz
Built-in speaker: No
Dimension:3.6 x 2.1x 0.6in
Weight: 40g / 0.09lb
